Tuff Tube®

Protect your equipment from spouting wear.

The patented Tuff-Tube® lining system, made with cast urethane, reduces abrasion in grain, seed, and fertilizer handling, preventing spouting wear. It addresses high maintenance costs and eliminates frequent steel spout replacements. Tuff-Tube® liners can rotate for added wear surfaces and are easily replaceable in existing spouts, avoiding annual new purchases. Available for standard spout diameters up to 20” and lengths up to 10’, Tuff-Tube safeguards spouting and boosts profits.

What is it?

Urethane spout-liner with a flanged steel end.

What is it used for?

Spout lining for handling abrasive bulk materials

Available Product Line

  • 10'

    • 4"

    • 6"

    • 8"

    • 10"

    • 12"

    • 14"

    • 16"

    • 18"

    • 20"

  • All elbow options are 22.5 Degrees.

    • 4" - 10ga galvanized

    • 6" - 10ga galvanized

    • 8" - 10ga galvanized

    • 10" - 10ga galvanized

    • 12" - 7ga galvanized

    • 14" - 7ga galvanized

Available Customization

The Tuff Tube® can be cut in the field to fit your exact spout length.

Top Industries Served

  • Combine pours grain into trailer

    01

    Feed, seed, and grain processing

  • Mining facility

    02

    Mining

  • 03

    Aggregate handling

  • 04

    Fertilizer

  • Sand pouring into bin

    05

    Frac Sand

View Industries

Seamless Spouting Application

Using Tuff Tube® eliminates vertical seams in your spouting liner system, preventing objects from getting in-between the liner and spout to create buckling, plugging, and peeling issues. Our lined spout elbows have a permanently bonded liner that matches up to the Tuff-Tube® liner for total spout protection.

Tuff-Tube Close Up

Tuff-Tube® is efficient for spouting applications:

  • Feed

  • Seed

  • Grain Processing

Conveyed material cannot force itself under lining:

Eliminates

  • Peeling Up

  • Buckling

  • Plugging

  • General spout failure

Lined spout elbows

  • Endurawear® Urethane liner permanently bonded to elbow

  • Available with and without a tapered leading edge

  • Matches up with Tuff-Tube® liner for total spout protection

Get a Quote on Tuff Tube®

Replacing your urethane spout liners is usually time sensitive and creates significant down time. We recognize that fact and pride ourselves in getting your product to you on-time. When you get your quote and place your order, you will know when we expect to have the Tuff-Tube® completed and ready for shipment.
